Obviously the vast array of possibilities make it almost impossible to list every possible variation of Air Break Switch Disconnector within these pages, however, listed below are the most common units supplied by Clydesdale, if the exact specification required is not listed please refer to Clydesdale for further assistance.
| Part No. |
Description |
Voltage |
Interupting Capacity |
Specification |
| CLY 200 A7435S |
Line Loadbreak Switch - 630A Ground Level Handle Operation |
24kV |
630A at 24kV |
Phase Elements fixed connections on both sides Includes Rods, Rod Guides and Rod Insulator, Mounting X-Arm for underslung installation |
| CLY 200 A7435HS |
Line Loadbreak Switch - 630A Hotstick Operation |
24kV |
630A at 24kV |
Phase Elements fixed connections on both sides Includes Rod & Rod Guide, Mounting X-Arm for underslung installation |
| CLY 200 A7522-1S |
Line Disconnector - 630A Ground Level Handle Operation |
24kV |
25A at 24kV |
Phase Elements fixed connections on both sides Includes X-Arm clamps for mounting on standard C-channels Suitable for mast head or underslung installation, also includes Rods, Rod Guides and Rod Insulator |
