Clydesdale can supply dual purpose aluminium tower ladders with the following features:
- Extruded, seamless, hollow aluminium rectangular sections
- Radiused corners for extra strength
- 30mm diameter corrugated tube rungs fitted through stiles at 250mm rise
- Special locking method to prevent rungs turning and added strength
- Ladder width 355mm
- Ends fitted with rubber plugs
| Part No. |
Rungs |
SWL |
Weight |
| CLY 910 15/12/376 |
15 |
180kg |
11kg |
| CLY 910 15/12/377 |
19 |
180kg |
21kg |
| CLY 910 15/12/378 |
21 |
180kg |
23kg |
| CLY 910 15/12/379 |
23 |
180kg |
25kg |
| CLY 910 15/12/382 |
12 |
180kg |
13kg |
| CLY 910 15/12/385 |
29 |
450kg |
31kg |
A full range of NG 151201 fittings are available:
| Part No. |
Description |
SWL |
Weight |
| CLY 910 15/12/353 |
Conductor Hook |
180kg |
11kg |
| CLY 910 15/12/354 |
Conductor Hook Support Plates |
180kg |
1.5kg/pr |
| CLY 910 15/12/356 |
Type A Tower Hook |
225kg ea. |
5kg/pr |
| CLY 910 15/12/357 |
Type B Tower Hook |
180kg |
13kg |
| CLY 910 15/12/358 |
Tower Plate |
225kg ea. |
3.5kg/pr |
| CLY 910 15/12/364 |
Alt. Type Hook A (flat bar) |
225kg ea. |
6.5kg/pr |
| CLY 910 15/12/365 |
Swivel Hook |
180kg |
3kg |
| CLY 910 15/12/366 |
Splice Plate |
90kg |
12kg/pr |
