360 Working Platform
CLY 910 XPLT
Tread
Aluminium
Glassfibre
Call: +44 (0) 1234 855 855 to order
The 360 Working Platform features:
550 x 400mm platform enclosed on three sides for safety
Optional webbing strap on the open side to provide complete
Glassfibre frame with aluminium treads
Ergonomically designed for industrial work
Insulated and non-conductive in use - complies with ANSI A14.5 and ESI 13-1
Compliant with HSE Work at Height Regs 2005 to work two-handed for short duration jobs
Kitemarked BS EN 131
Optional extras include:
Security webbing strap across open side
Powder coated handrail
Plastic coated handrail
Wheels at rear
Outriggers
Laddertag for inspection and maintenance
Custom compnay marking for security
Detachable tool tray
Open mesh foot
Part No.
A/A Rung
G/F Rung
Closed Height
Platform Height
Weight
CLY 910 XLPT02
CLY 910 AFXPLT02
1.55m
0.46m
11.5kg
CLY 910 XLPT03
CLY 910 AFXPLT03
1.80m
0.71m
13.5kg
CLY 910 XLPT04
CLY 910 AFXPLT04
2.05m
0.96m
14.0kg
CLY 910 XLPT05
CLY 910 AFXPLT05
2.31m
1.19m
16.0kg
CLY 910 XLPT06
CLY 910 AFXPLT06
2.56m
1.44m
19.0kg
CLY 910 GL207
CLY 910 AF207
2.82m
1.64m
20.0kg
CLY 910 XLPT08
CLY 910 AFXPLT08
3.07m
1.89m
22.0kg
CLY 910 XLPT09
CLY 910 AFXPLT09
3.32m
2.19m
23.0kg
CLY 910 XLPT10
CLY 910 AFXPLT10
3.57m
2.44m
24.0kg
CLY 910 XLPT11
CLY 910 AFXPLT11
3.82m
2.69m
26.0kg
360 Working Platform
: Aluminium
CLY 910 XPLT
360 Working Platform
: Glassfibre
CLY 910 AFXPLT
